| Nominal hose size | Aero Flex Part Number | Braid Layers | Nominal Outside Diameter | Nominal inside Diameter | Minimum Centerline BR | Pressure Rating at 23°C |  |
 |
|||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Static | Dynamic | Max Working | Max Test | Nominal Burst | |||||||
| inch | mm | mm | kg/cm2 | kg/cm2 | kg/cm2 | kg/m | m | ||||
| 3/4″ | A20016020 A200161401020 A200162401020 |
0 1 2 |
27.0 28.5 30.0 |
20.5 | 70 | 170 | 3 64 102 |
4.5 96 154 |
68 256 410 |
0.245 0.475 0.730 |
50 |
| 1″ | A20016025 A200161401025 A200162401025 |
0 1 1 |
34.0 35.5 37.0 |
25.6 | 85 | 190 | 3 50 80 |
4.5 75 120 |
60 200 320 |
0.340 0.614 0.915 |
50 |
| 1 1/4″ | A20016032 A200161401032 A200162401032 |
0 1 2 |
41.0 42.5 44.0 |
32.6 | 105 | 260 | 2 40 64 |
3 60 96 |
55 160 256 |
0.390 0.802 1.243 |
50 |
| 1 1/2″ | A20016040 A200161401040 A200162401040 |
0 1 2 |
51.0 52.5 54.0 |
40.6 | 130 | 300 | 2 35 56 |
3 52.5 84 |
50 140 224 |
0.470 1.015 1.590 |
50 |
| 2″ | A20016050 A200161401050 A200162401050 |
0 1 2 |
65.0 67.0 69.0 |
50.7 | 160 | 320 | 1 30 48 |
1.5 45 72 |
45 120 192 |
0.680 1.444 2.256 |
50 |
| 2 1/2″ | A20016065 A200161401065 A200162401065 |
0 1 2 |
81.0 83.0 85.0 |
65.6 | 180 | 410 | 1 24 38 |
1.5 36 58 |
40 96 154 |
1.064 1.984 2.95 |
25 |
| 3″ | A20016080 A200161401080 A200162401080 |
0 1 2 |
95.0 97.0 99.0 |
80.3 | 200 | 450 | 0.6 18 29 |
0.9 27 43 |
35 72 115 |
1.098 2.154 3.260 |
25 |
| 4″ | A20016100 A200161401100 A200162401100 |
0 1 2 |
117.0 119.0 121.5 |
100.8 | 290 | 560 | 0.5 16 26 |
0.75 24 38 |
28 64 102 |
1.401 3.001 4.665 |
25 |
| 5″ | A20016125 A200161401125 A200162401125 |
0 1 2 |
150.0 152.5 155.0 |
125.4 | 325 | 710 | 0.5 14 22 |
0.8 21.0 34 |
25 56 90 |
2.667 4.887 7.196 |
10 |
| 6″ | A20016150 A200161401150 A200162401150 |
0 1 2 |
175.0 177.5 180.0 |
150.8 | 380 | 815 | 0.3 12 20 |
0.45 18 30 |
22 48 80 |
3.220 5.705 8.289 |
10 |
| 8″ | A20016200 A200161401200 A200162401200 |
0 1 2 |
225.0 228.0 231.0 |
197.0 | 500 | 1015 | 0.3 10 16 |
0.5 15.0 24 |
18 40 64 |
4.850 9.150 13.62 |
10 |
| 10″ | A20016250 A200161401250 A200162401250 |
0 1 2 |
278.0 281.5 285.0 |
250.4 | 620 | 1270 | 0.2 7.5 12 |
0.3 11 18 |
18 30 48 |
7.150 13.75 20.550 |
10 |
| 12″ | A20016300 A200161401300 A200162401300 |
0 1 2 |
336.0 339.5 343.0 |
300.2 | 725 | 1525 | 0.2 6 9.5 |
0.3 9 14 |
16 24 38 |
10.800 18.200 25.822 |
10 |
| Series A 200 Braided Annular Hose-On-Reel & Single Braid | |||
|---|---|---|---|
| Nominal hose size | Reel Qty | Reel Dia | Reel Width |
| Size(in) | mtrs | m | m |
| 3/4″ | 450 | 1050 | 700 |
| 1″ | 400 | 1050 | 700 |
| 1 1/4″ | 200 | 1050 | 700 |
| 1 1/2″ | 150 | 1050 | 700 |
| 2″ | 75 | 1050 | 700 |
| 2 1/2″ | 90 | 1200 | 900 |
| 3″ | 75 | 1200 | 900 |
| 4″ | 25 | Coil form | |
| 5″ | 10 | Straight length | |
| 6″ | 10 | Straight length | |
| 8″ | 10 | Straight length | |
| 10″ | 10 | Straight length | |
| 12″ | 10 | Straight length | |
