| Attribute | Details |
|---|---|
| Product | Knitted Shade Cloth |
| Material | H.D.P.E Tape/Mono |
| Size | 3m x 50m |
| Weight | 180 g/sqm |
| ASTM D 3776:2009 | |
| Shade Factor | 90% |
| AATC 183:2004 | |
| Tensile Strength | |
| ASTM D 5034:2009 | |
| Warp | 513.7 N (115.5 lbf) |
| Weft | 611.9 N (137.6 lbf) |
| Elongation | |
| Warp | 49.3 N |
| Weft | 30.30 N |
| Tearing Strength | |
| ASTM D 5587:2008 | |
| Warp | 223.7 N (50.3 lbf) |
| Weft | 30.30 N |
| Bursting Strength | |
| ASTM D 3787:2009 | |
| Puncture Resistance | |
| ASTM D 6797:2007 | |
| Bursting Strength | 196.60 N (44.2 lbf) |
| Puncture Resistance | 1627.9 kPa (236.1 psi) |
| Puncture Resistance | 872.0 N (195.6 lbf) |
